คุณสมบัติ | รายละเอียด |
---|---|
Coil Voltage | 24V ac |
Contact Configuration | DPST |
Mounting Type | DIN Rail |
Switching Current | 20A |
Number of Poles | 2 |
Latching | No |
Terminal Type | Screw |
Maximum Switching Voltage AC | 250V ac |
Coil Resistance | 42 Ω |
Coil Power | 3W |
Isolation Coil To Contact | 4kV |
Maximum Operating Temperature | +40°C |
Depth | 58.4mm |
Minimum Operating Temperature | -40°C |
Series | 22 Series |
Height | 84mm |
Contact Material | Silver Alloy |
Maximum Switching Power AC | 5 kVA |
