คุณสมบัติ | รายละเอียด |
|---|---|
| Stroke | 160mm |
| Bore | 63mm |
| Action | Double |
| Manufacturer Series | DSBC |
| Length | 353.1mm |
| Pneumatic Connection | G 3/8 |
| Piston Rod Thread Gender | Male |
| Cushioning Type | Pneumatic Cushioning |
| Dimensions | 353.1 x 75 x 75mm |
| Width | 75mm |
| Maximum Operating Pressure | 12 bar |
| Height | 75mm |
| Test Weight | 1740 g @ 0 mm Stroke |
| Stroke Interval Weight | 62 g @ 10 mm Stroke |
| Maximum Operating Temperature | +80°C |
| ISO Standard | 15552 |
| VDMA Standard | 24562 |
| Weight | 1.7kg |
| Model Number p | 1383584 |
| Minimum Operating Temperature | -20°C |
