คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 12V dc |
| Contact Configuration | SPST |
| Mounting Type | Plug In |
| Number of Poles | 1 |
| Latching | No |
| Terminal Type | Quick Connect |
| Maximum Switching Voltage DC | 30V dc |
| Length | 28.3mm |
| Coil Resistance | 90Ω |
| Coil Power | 1.81W |
| Life | 10000000 Operations |
| Height | 25mm |
| Contact Material | AgSnOInO |
| Depth | 28.3mm |
| Isolation Coil To Contact | 500Vrms |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +125°C |
| Application | Automotive, Industrial |
RM85-2011-35-1009
G4W-2214P-US-HP 12DC
40.52.9.012.4000
