คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
---|---|
Monitoring Application | Voltage |
Supply Voltage | 24 → 240 V ac/dc |
Contact Configuration | DPDT |
Voltage Sensitivity | Overvoltage, Undervoltage |
Voltage Sensing Range | 15 → 600 V |
Time Delay | 0.1 → 3 s |
Minimum Voltage Sensed | 15 V |
Width | 35mm |
Maximum Voltage Sensed | 600V |
Length | 69mm |
Operating Temperature Range | -20 → +50 °C |
Maximum Operating Temperature | +50°C |
Height | 92.6mm |
Dimensions | 69 x 35 x 92.6 mm |
Minimum Operating Temperature | -20°C |
