คุณสมบัติ / Specifications
| คุณสมบัติ | Value |
|---|---|
| Output Voltage | 30/±15V dc |
| Input Voltage Range | 9 → 36 V dc |
| Input Voltage Nominal | 24 V dc |
| Isolation Voltage | 500 V dc, 1500 V dc |
| Power Rating | 30W |
| Output Current | 1A |
| Mounting Type | PCB Mount |
| Number of Outputs | 2 |
| Efficiency | 87% |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Load Regulation | 600mV |
| Line Regulation | 75mV |
| Series | MGFW |
| MTBF | 568000h |
| Maximum Input Current | 1.44A |
| Length | 25.4mm |
| Weight | 40g |
| Protection Features | Over Current Protection, Over Voltage Protection |
| Depth | 9.9mm |
| Width | 50.8mm |
| Ripple And Noise | 150mV Pk-Pk |
| Allowed Circuit Configurations | Series |
| Special Features | Built-In Remote ON/OFF, Efficient, Reliable, 6 Sided Shield |
| Output Voltage Adjustment Range | 14.602 → 15.505V |
| Power Signal Conversion Type | DC-DC |
| Standards Met | CE, CUL, CULus Recognised, EN 60950-1, TUV, UL 60950-1 |
