คุณสมบัติ / Specifications
| คุณสมบัติ | Value |
|---|---|
| Output Voltage | 28V dc |
| Input Voltage Range | 200 → 400 V dc |
| Input Voltage Nominal | 280 V dc |
| Isolation Voltage | 500 V dc, 3000 V ac |
| Power Rating | 50.4W |
| Output Current | 1.8A |
| Mounting Type | PCB Mount |
| Number of Outputs | 1 |
| Efficiency | 82% |
| Minimum Temperature | -40°C |
| Maximum Temperature | +100°C |
| Load Regulation | 56mV |
| Line Regulation | 56mV |
| Protection Features | Over Current Protection, Over Voltage Protection, Thermal Production |
| Current Limiting Method | Hiccup Current Limiting |
| Weight | 60g |
| Standards Met | CE, CUL, CULus Recognised, EN 60950-1, UL 60950-1 |
| Maximum Input Current | 220mA |
| Depth | 12.7mm |
| Width | 37.3mm |
| Ripple And Noise | 250mV Pk-Pk |
| Allowed Circuit Configurations | Series |
| Special Features | Built-In Over Current Protection, Built-In Remote ON/OFF, Efficient, High Density, Over Voltage & Thermal Protection Circuits, Reliable |
| Output Voltage Adjustment Range | 25.2 → 30.8V |
| Application | Automation, Industrial |
| Power Signal Conversion Type | DC-DC |
| Length | 58.4mm |
| MTBF | 522000h |
| Series | DHS |
