คุณสมบัติ / Specifications
| คุณสมบัติ | Value |
|---|---|
| Output Voltage | 12V dc |
| Input Voltage Range | 36 → 76 V dc |
| Input Voltage Nominal | 48 V dc |
| Isolation Voltage | 500 V dc, 1000 V ac, 2250 V dc |
| Power Rating | 396W |
| Output Current | 33A |
| Mounting Type | PCB Mount |
| Number of Outputs | 1 |
| Package | DIP |
| Efficiency | 95% |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Load Regulation | ±12mV |
| Line Regulation | ±12mV |
| Special Features | Built-In Over Current Protection, Built-In Remote ON/OFF, High Density, Over Voltage & Thermal Protection Circuits, Reliable |
| Allowed Circuit Configurations | Series |
| Ripple And Noise | 180mV Pk-Pk |
| Width | 37.3mm |
| Weight | 90g |
| Current Limiting Method | Hiccup Current Limiting |
| Output Voltage Adjustment Range | ±10% |
| Application | Automation, Industrial |
| Power Signal Conversion Type | DC-DC |
| Series | CHS |
| MTBF | 256000h |
| Length | 58.9mm |
| Protection Features | Over Current Protection, Over Voltage Protection, Thermal Production |
| Maximum Input Current | 8.68A |
| Depth | 12.7mm |
| Standards Met | CE, CUL (CSA 60950-1), CULus Recognised, EN 60950-1, UL 60950-1 |
