คุณสมบัติ / Specifications
| คุณสมบัติ | Value |
|---|---|
| Output Voltage | 12V dc |
| Input Voltage Range | 36 → 76 V dc |
| Input Voltage Nominal | 48 V dc |
| Isolation Voltage | 500 V dc, 1000 V ac, 2250 V dc |
| Power Rating | 192W |
| Output Current | 16A |
| Mounting Type | PCB Mount |
| Number of Outputs | 1 |
| Package | DIP |
| Efficiency | 94% |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Load Regulation | ±10mV |
| Line Regulation | ±10mV |
| Length | 58.4mm |
| Weight | 45g |
| Current Limiting Method | Hiccup Current Limiting |
| Protection Features | Over Current Protection, Over Voltage Protection, Thermal Production |
| Maximum Input Current | 4.26A |
| Depth | 10.5mm |
| Width | 22.26mm |
| Ripple And Noise | 180mV Pk-Pk |
| Allowed Circuit Configurations | Series |
| Special Features | Built-In Over Current Protection, Built-In Remote ON/OFF, High Density, Over Voltage & Thermal Protection Circuits, Reliable |
| Application | Automation, Industrial |
| Output Voltage Adjustment Range | ±10% |
| Standards Met | CE, CUL (CSA 60950-1), CULus Recognised, EN 60950-1, UL 60950-1 |
| Power Signal Conversion Type | DC-DC |
| MTBF | 341000h |
| Series | CHS |
