คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Actuator Type | Roller |
| Pole and Throw Configuration | DPST |
| Normal State Configuration | 2NC |
| IP Rating | IP65 |
| Maximum Current | 10 A |
| Housing Material | Glass Fibre Reinforced Thermoplastic |
| Maximum AC Voltage | 240V |
| Maximum DC Voltage | 240V |
| Connection Type | Screw |
| Series | TI2 |
| Contact Type | Slow Action, Snap Action |
| Length | 30mm |
| Width | 63.3mm |
| Mounting Orientation | Screw |
| Depth | 27mm |
| Minimum Operating Temperature | -30°C |
| Mechanical Life Minimum | 3000000 cycles |
| Maximum Operating Temperature | +80°C |
| Dimensions | 30 x 63.3 x 27 mm |
