คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Actuator Type | Roller |
| Pole and Throw Configuration | DPST |
| Normal State Configuration | NC/NO |
| IP Rating | IP66, IP67 |
| Maximum Current | 5 A |
| Housing Material | Glass Fibre Reinforced Thermoplastic |
| Maximum AC Voltage | 240V |
| Maximum DC Voltage | 24V |
| Connection Type | Screw |
| Series | IN65 |
| Contact Type | Slow Action, Snap Action |
| Length | 31mm |
| Width | 74mm |
| Mechanical Life Minimum | 20000000 cycles |
| Minimum Operating Temperature | -30°C |
| Operating Force | 10N |
| Depth | 30.3mm |
| Maximum Operating Temperature | +75°C |
| Dimensions | 31 x 74 x 30.3 mm |
| Mounting Orientation | Screw |
