รายละเอียดสินค้า / Product Details
| Attribute | Value |
|---|---|
| Detection Range | 60 → 400 mm |
| Output Type | PNP |
| Body Style | Block |
| Transducer Frequency | 400kHz |
| Maximum DC Voltage | 30V |
| Supply Voltage | 12 → 30 V dc |
| Terminal Type | M12 Connector |
| IP Rating | IP67 |
| Housing Material | Die Cast Zinc |
| Reverse Polarity Protection | Yes |
| Short Circuit Overload Protection | Yes |
| Dimensions | 65 x 30 x 31.1 mm |
| Response Time | 25 ms |
| Switching Current | 200 mA |
| Width | 30mm |
| Maximum Operating Temperature | +60°C |
| Length | 65mm |
| Depth | 31.1mm |
| Minimum Operating Temperature | -25°C |
