คุณสมบัติ | รายละเอียด |
|---|---|
| Series | SLL |
| Beam Resolution | 23mm |
| Component Type | Emitter, Receiver |
| SIL IEC 61508 | 3 |
| PL EN ISO 13849-1 | e |
| Protective Height | 700mm |
| Maximum Scanning Distance | 12m |
| Maximum Response Time | 13.3 ms |
| Length | 704mm |
| Height | 45mm |
| Supply Voltage | 24 V dc |
| Application | Area |
| Dimensions | 704 x 36 x 45 mm |
| Width | 36mm |
| Features | EDM, Fault Out and Amp, Fault Reset |
| Terminal Type | 8-Pin Quick Disconnect |
