คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Power Rating | 5.5 kW |
| Phase | 3 |
| Supply Voltage | 380 → 480 V |
| Current Rating | 12.5 A |
| Output Frequency | 0 → 600Hz |
| For Use With | 5.5 kW AC Motor |
| Ambient Temperature | -10 → +40°C |
| Overall Width | 169mm |
| Overall Length | 236mm |
| Overall Depth | 195mm |
| Control Panel | No |
| Drive Type | Vector Control |
| Filter Included | Yes |
| Standards Met | C-Tick, CE, CUL, EMC Directive 2004/108/EC, Environmental System ISO 14001, GOST R, Low Voltage Directive 2006/95/EC, Machinery Directive 2006/42/EC, Quality Assurance System ISO 9001, UL |
| Mounting Type | Cabinet, DIN Rail |
| Special Features | Flash Drop Tool, Programmable Control Connection, Safe Torque-Off Function, Sequence Programming, Serial and Ethernet Communication, Speed Compensated Stop |
| Series | ACS355 |
| Function | Motor Control |
| IP Rating | IP20 |
